The architecture in one paragraph
Microsoft describes the on-premises data gateway as locally installed Windows software that connects the Power BI service to data sources in an on-premises network, using outbound connections so that no inbound ports are opened, and it lists three options: standard mode for centrally managed shared connections, DirectQuery, live connections and clusters; personal mode for one user's Import refreshes; and the Microsoft-managed virtual network data gateway for sources inside an Azure virtual network (Microsoft Learn, On-premises data gateways in Power BI, accessed 2026-10-20). The enterprise pattern EPC Group's Power BI consulting practice builds follows from that: standard-mode gateways only, on dedicated always-on servers close to the data, grouped into clusters of two or more members per workload and per environment, with connections owned by named stewards, access granted to security groups, and the gateway's own logs feeding a monitoring report. Most refresh failures EPC Group investigates trace back to one of those decisions being skipped.
Standard versus personal mode
Microsoft's comparison is unambiguous. The standard gateway serves Power BI, Power Apps, Power Automate, Azure Logic Apps, Azure Analysis Services and Power BI dataflows (legacy); runs under credentials configured by authorized gateway users; installs only as a local administrator; and supports centralized gateway and data source management, Import and scheduled refresh, DirectQuery and live connection to Analysis Services. Personal mode serves Power BI only, runs under the installing user's Windows credentials or per-source credentials, and supports only Import semantic models with scheduled or on-demand refresh. It does not support DirectQuery, live connections, composite models, virtual network data gateways, clustering or high availability (Microsoft Learn, Use a personal gateway in Power BI, accessed 2026-10-20). A machine can host one gateway of each mode, never two of the same mode (Microsoft Learn, Install an on-premises data gateway, accessed 2026-10-20). EPC Group inventories personal gateways during governance reviews, because a certified semantic model refreshing through an analyst's laptop is an availability risk the tenant cannot see until it fails.
Sizing the gateway machine
Microsoft's installation requirements set the baseline: .NET Framework 4.8 and a supported Windows or Windows Server version at minimum, with an 8-core CPU, 8 GB of memory, a 64-bit edition of Windows Server 2019, 2022 or 2025, and solid-state storage for spooling recommended. Gateways are not supported on Server Core or Windows containers, cannot be installed on a domain controller, and should not run on a machine that sleeps, uses wireless networking or shares resources with other applications; Windows authentication to sources requires the gateway machine to be in the same directory environment as the sources (Microsoft Learn, Install an on-premises data gateway, accessed 2026-10-20).
Microsoft's sizing guidance adds the method. Start with at least 8 CPU cores, 8 GB of RAM and multiple Gigabit network adapters, measure a typical workload with CPU and memory counters, and plan for reliable, low-latency connectivity in both directions: fewer hops between gateway and source, no proxy throttling, Azure ExpressRoute where appropriate, and good connectivity to Active Directory for live connections that use dynamic row-level security (Microsoft Learn, On-premises data gateway sizing, accessed 2026-10-20). Microsoft's implementation planning guidance explains why the workload type matters: for Import models, the number of refreshes drives resource needs such as RAM, while for DirectQuery and live connections the number of report consumers drives needs such as CPU (Microsoft Learn, Power BI implementation planning: Data gateways, accessed 2026-10-20). EPC Group therefore separates Import refresh and DirectQuery traffic onto different clusters once either grows, rather than adding cores to a shared one.
Clustering and load balancing for high availability
A cluster is a set of gateways on different machines registered as one logical gateway. Each cluster supports up to 10 members; the gateway cloud service always uses the primary member unless it is unavailable, then moves to the next; management operations such as granting admin permissions or adding connections apply to every member; and members should run the same gateway version. With Distribute requests across all active gateways in this cluster enabled, members are selected at random, and administrators can add throttling in the Microsoft.PowerBI.DataMovement.Pipeline.GatewayCore.dll.config file with CPUUtilizationPercentageThreshold, MemoryUtilizationPercentageThreshold and ResourceUtilizationAggregationTimeInMinutes, which defaults to 5 minutes; a request fails only if every member is over its limit. Microsoft also recommends disabling or removing offline members rather than leaving them registered (Microsoft Learn, Manage on-premises data gateway high-availability clusters and load balancing, accessed 2026-10-20).
For business-critical use, Microsoft advises against a single cluster for an entire company, recommends a minimum of two gateways per cluster, and illustrates separate clusters for enterprise BI, individual departments and personal workloads (Microsoft Learn, Plan, scale, and maintain a business-critical gateway solution, accessed 2026-10-20). It also recommends separate clusters per development, test and production environment and updating one cluster member at a time, at least quarterly, to avoid downtime (Microsoft Learn, Power BI implementation planning: Data gateways, accessed 2026-10-20). The recovery key entered at installation is what lets a new machine join or replace a member, and Microsoft cannot retrieve it (Microsoft Learn, Install an on-premises data gateway, accessed 2026-10-20), so EPC Group stores it in the client's credential vault on day one.
Connections, roles and monitoring
Access is two-layered. Gateway roles are Admin, Connection creator and Connection creator with sharing; connection roles are Owner, User and User with sharing, and only an Owner can see or update stored credentials (Microsoft Learn, Manage security roles of an on-premises data gateway, accessed 2026-10-20). Credentials are encrypted so they cannot be decrypted in the cloud and are decrypted only on the gateway machine (Microsoft Learn, Add or remove a gateway data source, accessed 2026-10-20). For monitoring, standard gateways log by default to four reports, with query durations, spooling times and the SystemCPUPercent, SystemMEMUsedPercent, GatewayCPUPercent and GatewayMEMKb counters; Microsoft supplies a Power BI template for them, notes that the StreamBeforeRequestCompletes setting can speed loads at some reliability cost, and advises watching spooler disk space (Microsoft Learn, Monitor and optimize on-premises data gateway performance, accessed 2026-10-20). EPC Group's Power BI admin and governance support team consolidates those files across members and reviews them with the refresh history on a cadence set per engagement in the SOW.
Scope, deliverables and acceptance criteria
A gateway engagement from EPC Group's Power BI practice covers every gateway registered in the tenant, personal-mode installations included, and the semantic models, dataflows and connections that depend on them.
- Deliverables: a gateway inventory, a cluster design by workload and environment, machine specifications backed by measured CPU and memory counters, a role and connection-ownership model, a recovery-key custody record, and a monitoring report built on the gateway performance logs.
- Acceptance criteria: every shared or certified semantic model refreshes through a standard-mode cluster of at least two members; no shared content depends on a personal-mode gateway; every recovery key is stored where authorized administrators can retrieve it; all members of a cluster run the same gateway version; and the monitoring report shows failed refreshes and offline members.
Documented work
Anonymized engagement: EPC Group engagement data for gateway architecture covers mid-size and large manufacturing and energy organizations moving refreshes off single gateway servers and personal-mode gateways onto clustered standard-mode gateways separated by workload and environment, delivered by the firm's Power BI consulting practice. Client names are not published here. Engagements are described by industry and organization size only, and no outcome figures are quoted that cannot be traced to a signed deliverable. EPC Group is a Microsoft Solutions Partner with all six Solutions Partner Designations as of October 2026.
Primary sources
- On-premises data gateways in Power BI — Microsoft Learn, accessed 2026-11-22
- Use a personal gateway in Power BI — Microsoft Learn, accessed 2026-11-22
- Install an on-premises data gateway — Microsoft Learn, accessed 2026-11-22
- On-premises data gateway sizing — Microsoft Learn, accessed 2026-11-22
- Manage on-premises data gateway high-availability clusters and load balancing — Microsoft Learn, accessed 2026-11-22
- Plan, scale, and maintain a business-critical gateway solution — Microsoft Learn, accessed 2026-11-22
- Power BI implementation planning: Data gateways — Microsoft Learn, accessed 2026-10-20
- Manage security roles of an on-premises data gateway — Microsoft Learn, accessed 2026-10-20
- Add or remove a gateway data source — Microsoft Learn, accessed 2026-10-20
- Monitor and optimize on-premises data gateway performance — Microsoft Learn, accessed 2026-11-22
- Adjust communication settings for the on-premises data gateway — Microsoft Learn, accessed 2026-11-22
Frequently Asked Questions
What is the Power BI on-premises data gateway used for?
The on-premises data gateway is Windows software installed in your network that lets the Power BI service query or refresh data it cannot reach directly over the internet, using outbound connections only (Microsoft Learn, On-premises data gateways in Power BI, accessed 2026-11-22). The standard-mode gateway also serves Power Apps, Power Automate, Azure Logic Apps and Azure Analysis Services (Microsoft Learn, Use a personal gateway in Power BI, accessed 2026-11-22). EPC Group places it on dedicated servers close to the data.
What types of Power BI gateway are there?
Power BI supports three: the on-premises data gateway in standard mode, for centrally managed shared connections, DirectQuery, live connections and high-availability clusters; personal mode, for one user refreshing their own Import semantic models; and the Microsoft-managed virtual network (VNet) data gateway (Microsoft Learn, On-premises data gateways in Power BI, accessed 2026-11-22). Personal mode does not support DirectQuery, live connections, composite models, clustering or high availability (Microsoft Learn, Use a personal gateway in Power BI, accessed 2026-11-22).
How is a gateway cluster built and load-balanced?
Install a standard gateway, then install another on a second machine and add it to the cluster with the gateway's recovery key (Microsoft Learn, Install an on-premises data gateway, accessed 2026-11-22). A cluster holds up to 10 members and routes requests to the primary unless it is unavailable; load balancing spreads requests, and CPU and memory thresholds skip overloaded members (Microsoft Learn, Manage on-premises data gateway high-availability clusters and load balancing, accessed 2026-11-22). Use at least two gateways per cluster.
Which ports does the Power BI gateway need?
The gateway needs outbound access only: Microsoft lists outbound TCP 80, 443, 1433, 5671, 5672 and 9350 through 9354, and states that the gateway does not require inbound ports (Microsoft Learn, Adjust communication settings for the on-premises data gateway, accessed 2026-11-22). After registration only the Azure Relay endpoints are required, and the Network ports test in the gateway app shows any blocked endpoint (same source). EPC Group runs that test from every cluster member before go-live.
How should a gateway machine be sized?
Start with at least 8 CPU cores, 8 GB of RAM and multiple Gigabit network adapters, then measure CPU and memory counters (Microsoft Learn, On-premises data gateway sizing, accessed 2026-11-22). Use 64-bit Windows Server 2019, 2022 or 2025, never Server Core, Windows containers or a domain controller (Microsoft Learn, Install an on-premises data gateway, accessed 2026-11-22). Import refresh is limited by memory, DirectQuery and live connections by CPU (Microsoft Learn, Plan, scale, and maintain a business-critical gateway solution, accessed 2026-11-22).
How is gateway performance monitored?
Performance logging is on by default for standard-mode gateways and writes four logs, the Query Execution, Query Start, Query Execution Aggregation and System Counter Aggregation reports, aggregated every 5 minutes by default; Microsoft's Gateway Performance Power BI template visualizes them (Microsoft Learn, Monitor and optimize on-premises data gateway performance, accessed 2026-11-22). Microsoft also advises watching spooler disk space. EPC Group lands the logs centrally and alerts on failed refreshes and offline members.
